Resin Diamond Disc For Cutting EMC Package

Diamond Disc For Cutting EMC Package

EMC cutting mainly considers burr removal and cutting efficiency improvement. Our resin dicing blades perform excellently in the cutting process.

EMC has been widely used in LED brackets in recent years. By changing the filler and adding silica powder to make it white, it has greatly improved the air tightness, high temperature aging resistance, and UV attenuation resistance of traditional LED PPA brackets. It also has the characteristics of small size and low cost, and has gradually become a new choice for LED packaging factories.

Product

Diamond Grinding Wheels

Resin bond diamond disc for cutting EMC Package ( Epoxy Molding Compound) has sharpness, good cutting quality and no burrs.

About EMC ( Epoxy Molding Compound) Package

With the maturity of LED lighting application, the demand of medium power LED is rapidly increasing. In recent years, LED package factories have actively introduced EMC brackets suitable for medium and high power applications. When discussing the future development trend of LED package, EMC brackets are undoubtedly a major focus of the package industry, and EMC and SMC package will become a trend in future.

EMC is a highly integrated framework form that uses new epoxy materials and etching technology in the package of molding equipment. Compared to PPA and ceramic substrates, EMC package is made of epoxy resin, which can achieve large-scale production, reduce the production costs and provide more flexible design. EMC has advantages in certain fields that ceramic and PPA cannot match. With the future development trend of the industry, the continuous development of package technology and the decline in prices, it will drive the arrival of LED lighting era.

EMC bracket is suitable for package application of LED medium and high powder beads, and can ultimately be used for lighting or backlighting. Compared with traditional PPA, PCT and other brackets, LED brackets have high heat resistance, high current, high power, high density, UV resistance and small size, making them suitable for large-scale production applications.

Test Results of Resin Diamond Disc For Cutting EMC Package

Pre cutting and dressing blade:
1. Choose 400 # resin dressing board
2. Spindle speed 27K, cutting into the dressing board 0.3mm,
3.First, dress 5 cuts with a feed rate of 5mm/s, and then dress 10 cuts with a feed rate of 10mm/s.
Test results:
No obvious burrs and chipping, with a life of up to 6000 meters
